ASUS ProArt X870E-Creator WIFI AM5 ATX Motherboard, AMD X870E Chipset, 4x DDR5 DIMM Slots, 192GB Max Memory, 4x M.2 PCIe Slots, 2x PCIe 5.0 x16 Slots, Bluetooth v5.4 | 90MB1IG0-M0EAY0

SKU AMB1039Model ProArt X870E-Creator WIFIPart No 90MB1IG0-M0EAY0

AED 1,899

Availability: In stock (16)
Warranty: 3 Years Limited Warranty

Delivery across the UAE — options and charges
Returns on eligible items — what qualifies
3 Years Limited Warranty warranty — how claims work
Secure payment — your card details never reach us

Key features

NameASUS ProArt X870E-Creator WIFI Motherboard
Part No.90MB1IG0-M0EAY0
SocketAMD AM5
ChipsetAMD X870E
Memory4 x DDR5 DIMM, Up to 256GB
SeriesProArt

Description

The ASUS ProArt X870E-Creator WIFI is a premium ATX AM5 motherboard designed for content creators, professional workstations and high-performance AMD Ryzen systems. It supports Ryzen 9000, 8000 and 7000 Series desktop processors, four DDR5 DIMMs up to 256GB and memory speeds up to 8000+ MT/s (OC). Expansion includes two PCIe 5.0 x16 SafeSlots plus four M.2 sockets, including two PCIe 5.0 x4 M.2 slots with Ryzen 9000/7000 processors. Professional networking includes Marvell 10Gb Ethernet, Intel 2.5Gb Ethernet, Wi-Fi 7 and Bluetooth 5.4. Dual USB4 40Gbps Type-C, HDMI 2.1, Realtek ALC1220P audio and creator-focused ASUS ProArt features complete the platform.

Specifications

General

Name: ASUS ProArt X870E-Creator WIFI Motherboard
Model: ProArt X870E-Creator WIFI
Part No.: 90MB1IG0-M0EAY0
Socket: AMD AM5
Chipset: AMD X870E
Memory: 4 x DDR5 DIMM, Up to 256GB

Product

Brand: ASUS
Series: ProArt
Type: Creator / Workstation ATX Motherboard
Form Factor: ATX
Dimensions: 30.5 x 24.4 cm / 12 x 9.6 in
EAN: 4711387730775

CPU

Socket: AMD AM5
Supported Processors: AMD Ryzen 9000 / 8000 / 7000 Series Desktop Processors

Chipset

Model: AMD X870E

Power

VRM: 16+2+2 Power Stages
Power Stage Rating: 80A
CPU Power: 2 x 8-Pin ProCool II +12V
Main Power: 1 x 24-Pin ATX

Memory

Slots: 4 x DDR5 DIMM
Maximum Capacity: 256GB
Maximum Speed: 8000+ MT/s OC
Architecture: Dual Channel
AMD EXPO: Supported
ASUS AEMP: Supported
ECC: ECC and Non-ECC Unbuffered DIMM Supported
On-Die ECC: Supported on Non-ECC Unbuffered DDR5

Expansion

Ryzen 9000 / 7000: 2 x PCIe 5.0 x16 SafeSlots
Dual GPU Mode: x8/x8
Alternate Bifurcation: x8/x4/x4 Depending on Configuration
Ryzen 8000 8700/8600/8400: Primary PCIe 4.0 x8, Second Slot Disabled
Ryzen 8000 8500/8300: Primary PCIe 4.0 x4, Second Slot Disabled
Chipset Slot: 1 x PCIe 4.0 x16 Physical, x4 Mode
PCIe Q-Release Slim: Yes
SafeSlot: Yes

Storage

M.2 Slots: 4
M.2_1: PCIe 5.0 x4 with Ryzen 9000/7000, PCIe 4.0 x4 with Ryzen 8000
M.2_2: PCIe 5.0 x4 with Ryzen 9000/7000
M.2_3: PCIe 4.0 x4 via X870E Chipset
M.2_4: PCIe 4.0 x4 via X870E Chipset, Supports Up to 22110
SATA: 4 x SATA 6Gb/s
PCIe RAID Ryzen 9000: RAID 0 / 1 / 5 / 10
PCIe RAID Ryzen 7000: RAID 0 / 1 / 10
PCIe RAID Ryzen 8000: RAID 0 / 1
SATA RAID: RAID 0 / 1 / 10
M.2 Q-Latch: Yes
M.2 Q-Release: Yes
M.2 Q-Slide: Yes
M.2 Heatsinks: Yes
M.2 Heatsink Backplate: Yes

Networking

10Gb Ethernet: 1 x Marvell AQtion 10GbE
2.5Gb Ethernet: 1 x Intel 2.5GbE
ASUS LANGuard: Yes

Wireless

Wi-Fi: Wi-Fi 7 2x2 / 802.11be
Wi-Fi Module: Qualcomm QCNCM865 or MediaTek MT7927 Depending on Unit
Bands: 2.4GHz / 5GHz / 6GHz
Maximum Channel Width: 320MHz
Bluetooth: Bluetooth 5.4
Antenna: ASUS WiFi Q-Antenna

Graphics

HDMI: 1 x HDMI 2.1
HDMI Maximum: 4K at 60Hz
USB4 Display Outputs: 2 x USB4 Type-C with DisplayPort 1.4 Alt Mode
USB4 Display Maximum: Up to 8K at 60Hz
DisplayPort Input: 1 x DisplayPort Input

USB

Rear USB Total: 11 Ports
Rear USB4 Type-C: 2 x 40Gbps
Rear USB 20Gbps Type-C: 1
Rear USB 10Gbps Type-A: 7
Rear USB 2.0 Type-A: 1
Front USB-C Header: 1 x USB 20Gbps with Up to 30W PD / QC4+
Front USB 5Gbps Header: 1 Header for 2 Ports
Internal USB 2.0 Headers: 3 Headers for 6 Ports

Audio

Codec: Realtek ALC1220P 7.1 HD Audio
Playback SNR: 120dB
Recording SNR: 113dB
Maximum Playback: Up to 32-Bit / 192kHz
Audio Shielding: Yes
Premium Audio Capacitors: Yes
Dedicated Audio PCB Layers: Yes

Rear I/O

USB4 Type-C: 2
USB 20Gbps Type-C: 1
USB 10Gbps Type-A: 7
USB 2.0 Type-A: 1
DisplayPort Input: 1
HDMI: 1
10GbE RJ-45: 1
2.5GbE RJ-45: 1
Audio Jacks: 3
BIOS FlashBack Button: 1
Clear CMOS Button: 1

Cooling

CPU Fan Header: 1
CPU OPT Fan Header: 1
AIO Pump Header: 1
Chassis Fan Headers: 5
VRM Heatsink: Yes

RGB

Addressable Gen 2 Headers: 3
Aura Sync: Supported

DIY

Q-Antenna: Yes
Q-Connector: Yes
Q-DIMM: Yes
Q-LED: CPU / DRAM / VGA / Boot Device
Pre-Mounted I/O Shield: Yes
BIOS FlashBack: Yes
Clear CMOS: Yes

Software

Armoury Crate: Supported
Aura Creator: Supported
Aura Sync: Supported
Fan Xpert 4 with AI Cooling II: Supported
ASUS DriverHub: Supported
ASUS GlideX: Supported
ProArt Creator Hub: Supported
CreationFirst: Supported
ASUS Control Center Express: Supported

BIOS

Flash ROM: 256Mb
Type: UEFI AMI BIOS
ASUS EZ Flash 3: Supported
ASUS CrashFree BIOS 3: Supported

Operating System

Windows: Windows 11

Package

DisplayPort Cable: 1
SATA 6Gb/s Cables: 4
ASUS WiFi Q-Antenna: 1
Q-Connector: 1
M.2 Q-Latch Package: 1
M.2 Q-Latch Q-Slide Package: 1
M.2 Rubber Packages: 2
M.2 22110 Thermal Pad: 1
Quick Start Guide: 1
ACC Express Activation Key Card: 1

Warranty

Standard: 3 Years Limited Warranty
Note: Warranty Period May Vary by Region

Use Case

Content Creation: Yes
Professional Workstation: Yes
10GbE Networking: Yes
Multi-GPU / High-Bandwidth Expansion: Yes
PCIe 5.0 NVMe Storage: Yes
Wi-Fi 7 Workstation: Yes

Reviews

No reviews yet for ASUS ProArt X870E-Creator WIFI AM5 ATX Motherboard, AMD X870E Chipset, 4x DDR5 DIMM Slots, 192GB Max Memory, 4x M.2 PCIe Slots, 2x PCIe 5.0 x16 Slots, Bluetooth v5.4 | 90MB1IG0-M0EAY0. Be the first to write one.
