Gigabyte GeForce RTX 5060 Ti AERO OC Graphics Card, GDDR7 16GB 128-bit Memory, HDMI 2.1b & DP 2.1b Outputs, PCI Express 5.0, 2647 MHz Core Clock, 28 Gbps​ Memory Clock, Triple Windforce RGB Hawk Fans, Dual Bios, White, 1 Year Warranty | GV-N506TAEROOC-16GD

GIGABYTESKU CFW1029Model GeForce RTX 5060 Ti AERO OC 16GPart No GV-N506TAERO OC-16GD
AED 3,479
Availability
In stock (10)
Warranty
1 Year Warranty
Qty

Key features

  • NameGIGABYTE GeForce RTX 5060 Ti AERO OC 16G
  • Part No.GV-N506TAERO OC-16GD
  • RAM16GB GDDR7
  • Core Clock2647 MHz
  • Memory Clock28 Gbps
  • TypeGaming / Creator Graphics Card

Description

The GIGABYTE GeForce RTX 5060 Ti AERO OC 16G is a white factory-overclocked NVIDIA Blackwell graphics card built for high-performance gaming, AI-enhanced graphics and creator workloads. It features 4,608 CUDA cores, 16GB of 28Gbps GDDR7 memory on a 128-bit interface and a 2647MHz factory OC core clock, above NVIDIA's 2572MHz reference boost clock. GIGABYTE's WINDFORCE cooling system combines Hawk fans, alternate spinning, composite copper heat pipes, a copper plate, 3D Active Fan semi-passive cooling, screen cooling and server-grade thermal conductive gel. The AERO design includes RGB lighting, Dual BIOS Performance/Silent modes and reinforced construction. Connectivity includes 3× DisplayPort 2.1b and 1× HDMI 2.1b.

Specifications

Specifications

Name
GIGABYTE GeForce RTX 5060 Ti AERO OC 16G
Model
GeForce RTX 5060 Ti AERO OC 16G
Part No.
GV-N506TAERO OC-16GD
RAM
16GB GDDR7
Core Clock
2647 MHz
Memory Clock
28 Gbps

Product

Type
Gaming / Creator Graphics Card
Series
GeForce RTX 50 Series
GPU
NVIDIA GeForce RTX 5060 Ti
Edition
AERO OC 16G
Manufacturer
GIGABYTE
URL Part Number
GV-N506TAERO-OC-16GD
UPC
889523049310
EAN
4719331356033
Colour
White / Silver

Architecture

GPU Architecture
NVIDIA Blackwell

Compute

CUDA Cores
4,608
Tensor Cores
5th Generation
AI Performance
759 AI TOPS
RT Cores
4th Generation
Ray Tracing Performance
72 TFLOPS

Clock

NVIDIA Reference Boost Clock
2572 MHz
NVIDIA Reference Base Clock
2410 MHz

Memory

Capacity
16GB
Type
GDDR7
Speed
28 Gbps
Interface
128-bit
Bandwidth
448 GB/s

Interface

Card Bus
PCI Express 5.0
Electrical Link
PCI Express 5.0 x8

Display

DisplayPort
3 x DisplayPort 2.1b
HDMI
1 x HDMI 2.1b
Maximum Simultaneous Displays
4
GIGABYTE Maximum Digital Resolution
7680 x 4320
NVIDIA Platform Maximum
Up to 4K at 480Hz or 8K at 165Hz with DSC
HDCP
2.3

API

DirectX
DirectX 12 API / DirectX 12 Ultimate Supported
OpenGL
OpenGL 4.6
Vulkan
Vulkan 1.4

Technology

NVIDIA DLSS
DLSS 4 platform
Super Resolution
Supported
DLAA
Supported
Ray Reconstruction
Supported
Frame Generation
Supported
Multi Frame Generation
Supported
NVIDIA Reflex
Reflex 2
NVIDIA Broadcast
Supported
NVIDIA G-SYNC
Supported
NVIDIA Studio
Supported
Game Ready Drivers
Supported
Studio Drivers
Supported
NVIDIA App
Supported
RTX Remix
Supported
Resizable BAR
Supported
NVIDIA NVLink
Not Supported

Video

NVENC
1 x 9th Generation
NVDEC
1 x 6th Generation
AV1 Encode
Supported
AV1 Decode
Supported

Compute API

CUDA Capability
12.0

Virtual Reality

VR Ready
Yes

Cooling

System
GIGABYTE WINDFORCE
Fan Design
Hawk Fan
Fan Count
Triple Fan
Alternate Spinning
Yes
3D Active Fan
Yes / Semi-Passive Fan Stop
Fan Lubricant
Graphene Nano Lubricant
GPU Contact
Copper Plate
Heat Pipes
Composite Copper Heat Pipes
Screen Cooling
Yes
VRAM and MOSFET Cooling
Server-Grade Thermal Conductive Gel

Lighting

RGB Lighting
Yes

BIOS

Dual BIOS
Performance / Silent

Construction

Reinforced Structure
Yes
Reinforced Backplate
Yes

Software

GIGABYTE Control Center
Supported

Form Factor

PCB Form
ATX
Slot Width
2 Slots / 40 mm

Dimensions

Length
281 mm
Width
117 mm
Height
40 mm
Card Size
281 x 117 x 40 mm

Weight

Card Weight
Approx. 0.82 kg

Power

NVIDIA Reference Total Graphics Power
180W
NVIDIA Reference Required System Power
600W
GIGABYTE Recommended PSU
650W
Power Connector
1 x PCIe 8-Pin

Thermal

NVIDIA Reference Maximum GPU Temperature
87°C

Accessories

Quick Guide
Included

Warranty

Listing / Seller Warranty
1 Year
GIGABYTE Manufacturer Policy
1 Years Limited Local Warranty
Manufacturer Note
Regional differences may apply
